Overview
Product Description
Quick Detail:
The small plastic profile extrusion line is mechanotronics, with the advantages of:
1) high production efficiency;
2) reasonable structure compact;
3) convenient operation and maintenance
4) long use life etc.
Description:
This small plastic profile extrusion line consists of single screw extrusion machine, vacuum calibrating platform, haul-off machine, cutting machine and stacker. There are many outstanding features of this small profile line, like good plasticizing, high output, low energy consumption etc.
Specification :
| model | YF60 | YF180 | YF240 | YF430 |
| extruder | SJSZ-45 | SJSZ-51 | SJSZ-65 | SJSZ-80 |
| Max width of profile(mm) | 60 | 180 | 240 | 300 |
| Output (kg/h) | 70-100 | 80-120 | 160-250 | 300-360 |
| Main motor power (kw) | 15 | 18.5 | 37 | 55 |
| Cooling water (m3 /h) | 4 | 5 | 7 | 7 |
| dimension | 15×1.2×1.5 | 18×1.2×1.6 | 22×1.5×1.8 | 26*1.6*1.8 |
REMARK : if the equipment or technological parameters have some change , we shall not make a notice separately
Advantage Feature:
1) Excellent weather resistance
2) Excellent heat insulation and energy saving
3) Excellent water resistance
4) Excellent sound proofing
5) Corrosion resistance
6) Excellent fire proofing
7) Attractive appearance
8) Environmentally friendly
9) Easy to clean
