500kg HDPE PP woven bag Plastic Pelletizing Extrusion Line

Main Technical Parameter

Model	Screw Diameter		L/D	Main Motor	Output	Cutting Method
SJ120/120	120		120	37KW	20	Die Face Cutting or Strands Cutting
			10	15KW	150-300KG/H
SJ140/130	140	140	20	55KW
SJ140/140	130	140	10	18.5KW	200-350KG/H
SJ150/140	150	150	20	75KW
SJ150/150	140	150	10	22KW	300-500KG/H
SJ160/150	160	160	20	90KW
SJ160/160	150	160	10	37KW	400-600KG/H

The capacity is based on the raw material. The output for rigid flake and film flake are different, as welll as the material. We offer solution based on the client's actural requirements.
